Dimensions and technical details 230 V ~ 50 Hz Housing colour: white Housing material: plastic, UV-resistant, non-yellowing Nominal size: 120 mm Speed levels: 1 Wattage: 13 W Current consumption: 0.095 A Revolutions per minute: 2075 Airflow rate: 175 m³/h Sound pressure level Lp-3m: 32.3 dB(A) Total pressure Pmax: 49.04 Pa Max. temperature for continuous operation: +50°C Protection class: IP45 Insulation class: II Weight: 0.8 kg Adjustable shut-off delay: 2 – 30 min Thermal overload protection Integral backdraught valve prevents cold air from infiltrating the system Ball-bearing motor Mounting options: wall, ceiling Application: air extraction in small bathrooms, utility rooms, etc. Dimensions in mm A B C D E F G H ØL MEX 120/5 LL 1S T 193 193 138 119 71 53 152 152 3.5
